Specially designed brackets transmit mechanical force with low vibration damping
Durable and reliable sensor possesses good linearity
Permanent calibration brings high accuracy with a permission of large initial unbalance amount
Belt-driving offers higher precision and easier operation
Advanced electrical measuring system and friendly man-machine interface
Modular design offers a wide range of application

Applicable to small workpieces

Technical data at a glance	PHQ-160H	PHQ-300H	PHQ-500H
Max Mass of Workpiece(kg)	160	300	500
Max Diameter of Workpiece (mm)	Φ1000	Φ1220	Φ1500
Distance Between Two Support Bearings (mm)	130~1270	130~1270	130~1270
Journal Diameter Scope of Workpiece (mm)	Φ 15~75³⁾	Φ 15~75³⁾	Φ 15~75³⁾
Diameter Scope of Driving Belt (mm)	Φmax400	Φmax500	Φmax600
Rotational Speed when the Diameter of Driving Belt is 100mm (r/min)	756,1176¹⁾	756,1176¹⁾	756,1176¹⁾
Motor Power (kw)	1.5²⁾	1.5²⁾	2.2²⁾
Length of Bed (mm)	1500	1500	1500
Min Achievable Residual Unbalance Amount (emar)	≤0.15g· mm/kg	≤0.15g· mm/kg	≤0.15· mm/kg

1) Stepless speed regulation
2) Frequency conversion

3) Can add to 75-180
4) Can add to 120-240
